High Speed Laminated Air Bubble Mailer Making Machine

High Speed Laminated Air Bubble Mailer Making Machine

This machine with is suitable for making Kraft paper laminated air bubble mailer, Kraft paper laminated PE foam bag, PET laminated air bubble bag ,  Co-extrusion PE film laminated air bubble bag, Pearlized BOPP laminated air bubble mailer, Aluminum foil laminated PE foam bag...etc. Two sides sealing bag.

The Bubble Envelope/Mailer making machine is specially designed for Kraft paper bubble shock- proof bag making machine, with based on the advanced foreign machinery using motion controller, 4-axis servo linkage technology, professional Automation, upgrade in innovation then the on-line composite Kraft paper bubble material or the off-line composite arch extrusion film bubble material is folded in half through the folding forming device and then through the needle exhaust gas, hot pressing horizontal sealing molding, on-line heat transfer glue spraying cover with release liner , and then cutting in the standard Laminated bubble envelope/mailer bag. The equipment adopts advanced mechanical , electrical , gas, photocell tracing, spraying glue etc. integrated control technology. From sheet material unwinding to cutting & forming out in bag, there are conveyor belt stacking and sending, all the processes are controlled by computer. The finished bag is smooth and beautiful, edges bonded firmly. The machine is easy to operation,  and it is a high-quality special bag-making equipment.



 Technical Parameters



Machine Name Air Bubble Mailer making machine Weight 4200KGS
Max bag-making width For Type-800:  Max bag width -780mm Machine Dimensions 21500x2600x2600(mm)
Computer display screen 800mm Total Power Three phase four wire 380V,23KW
Effective unwinding width Bubble film 1500mm Bag making speed 20~200pcs/min





 Machine Characteristics

01. Responsive, automatic correction

Double photocell tracing feeding, automatic constant tensions, control AC frequency conversion constant speed automatic feeding.

02. Double servo motors, double servo system 2.3KW : front end and back end :  1set for each end

The sealing knife moves forward and backward, 800 width copper hot sealing knife, 20 mm width knife touch surface, up and down total in 8sets. Cast iron sealing knife base ensures no deformation.

03. Single and double station of release liner and glue spray are available

With motion control technology,from sheet material unwinding to cutting & forming out in bag, the series action controlled by computer. The finished bag is smooth and beautiful, edges bonded firmly, and accurate edge correction.



04. Material Sheet unwinding

Stable output torque, faster response speed, high adaptation frequency, fast edge correction speed.
